Climate-Resilient Housing Systems for a Changing World
Deployable, cyclone-resistant modular housing designed for disaster recovery, remote communities, and scalable developments — powered by advanced Structural Insulated Panels (SIP) technology.
Barkly Housing Systems — Enabled by SipsPacific
The Housing Gap is Accelerating
Across the Pacific and cyclone-prone regions worldwide, communities face a growing shortage of resilient, affordable housing. Traditional construction is too slow, labour-intensive, and vulnerable to extreme weather.
Disaster recovery, remote development, and social housing now require a different approach — one designed for speed, durability, and deployment at scale.
Barkly Rapid Deploy Housing System
Barkly is an integrated modular housing platform engineered for rapid deployment in demanding environments. The system combines five core components working seamlessly together to deliver climate-resilient, affordable housing solutions.
Integrated System Components
3×6 Modular Box
The core structural unit designed for rapid assembly and deployment. Provides the foundation for flexible configurations.
Mega Anchor Footings
Innovative concrete-free foundation system enabling minimal site preparation and rapid installation on diverse terrain.
Steel Framing System
Engineered structural frame providing cyclone-tested strength and durability in extreme weather conditions.
FRP-PU Windows & Doors
Fiber-reinforced polymer composite windows and doors offering superior thermal performance and corrosion resistance.
SIP Panel Technology
Advanced Structural Insulated Panels developed by SipsBuild (Perth) and tested/approved by Curtin University for thermal efficiency and structural integrity.
Barkly Steel Framing System
Barkly Complete System with Mega Anchor Footings
Scalable Configurations
The modular design allows multiple 3×6 units to be connected using the steel framing system, creating larger buildings and multi-unit complexes. From single cabins to community-scale facilities, Barkly adapts to your needs.
- ✓Single 3×6 unit for individual accommodation
- ✓Multiple units combined for larger facilities
- ✓Rapid assembly of multi-unit complexes
- ✓Flexible expansion as needs grow
Multiple Units Combined for Larger Facilities
Cyclone-Resilient Design
Engineered to withstand extreme weather and structural demands
Energy Efficient
Advanced building envelope reduces heating and cooling costs by up to 50%
Minimal Site Prep
Concrete-free footing system requires minimal ground disturbance
Rapid Deployment
Delivered in weeks rather than years with flatpack logistics
Adaptable Layouts
Flexible configurations for multiple uses and applications
Community Scale
From emergency accommodation to permanent communities
Why Structural Insulated Panels (SIP)?
SipsBuild's advanced SIP technology delivers superior performance across thermal efficiency, structural integrity, and construction speed. Our panels are engineered for durability and environmental responsibility.
Thermal Performance & Energy Savings
Up to 50% Heating/Cooling Reduction
Continuous insulation throughout walls, roofs, and floors eliminates thermal bridging
Superior Air Tightness
Airtight building envelope creates a controlled, healthy internal environment
Net-Zero Energy Ready
High R-values (R3.2 to R4.6 per inch) enable net-zero energy buildings
Durability & Resilience
Cyclone-Tested Strength
Panels tested to withstand 2.5x cyclone loading requirements
Non-Combustible Materials
Magnesium Oxide or Fibre Cement board skins provide fire resistance
Corrosion Resistant
Ideal for coastal climates with advanced composite technology
Construction Efficiency
Hours to Days
Lock-up stage completed on-site or in factory
Factory Built
Complete modules fully fitted out for rapid installation
Minimal Waste
Precision manufacturing reduces construction waste and rework
Mega Anchor: Patented Micro Pile Foundation System
Mega Anchor is a high-strength, galvanised steel micro pile foundation system engineered to replace traditional concrete piers. Designed for rapid deployment with minimal site preparation, Mega Anchor enables fast, cost-effective foundation installation for buildings, fencing, and solar projects.
System Overview
Installation Method
Three galvanised steel piles per footing, hand-driven using a portable jackhammer to refusal. Average installation depth: 2 metres. No concrete required.
Key Advantages
- ✓ Concrete-free foundation system
- ✓ Rapid installation on diverse terrain
- ✓ Minimal site preparation required
- ✓ Portable, hand-operated installation
- ✓ Galvanised steel for corrosion resistance
Applications
Modular buildings, emergency housing, fencing systems, solar installations, and any structure requiring rapid, reliable foundation deployment.
3-Pile Installation System
Installed Mega Anchor Foundation
Real-World Deployment
Beechworth, Victoria — Solar Project
Large-scale solar installation using Mega Anchor footings for rapid deployment across challenging terrain. The system enabled fast foundation installation without concrete curing delays.
_b8e7f92c.JPG)
Dublin — Fencing Installation
Structural fencing project demonstrating Mega Anchor's versatility for non-building applications. The system provides reliable, corrosion-resistant support in demanding environments.
GFRPU Windows & Doors: Shanghai G-Ren Advanced Composite Technology
Shanghai G-Ren New Material Science and Technology Co., Ltd manufactures certified, energy-efficient glass fiber-reinforced polyurethane (GFRPU) composite windows and doors. Engineered for passive house performance and tested to Australian standards, GFRPU components deliver superior thermal efficiency, durability, and lightweight structural performance.
Technical Performance
Structural Strength (AS/NZS 4420.1-2016)
- ✓ Serviceability Design Wind Pressure: ±800 Pa
- ✓ Ultimate Strength: ±3000 Pa with no collapse
- ✓ Excellent deflection control (Stile 1/1008, Rail 1/300)
Air Tightness & Weather Protection
- ✓ Air Infiltration: 0.37-0.40 L/s·m² at ±75 Pa (excellent)
- ✓ Water Penetration: No leakage at 600 Pa
- ✓ EPDM weather-strip and gaskets for durability
Operational Excellence
- ✓ Operating Force: 34N open / 32N close (smooth operation)
- ✓ Maintenance Force: 15N open / 14N close
- ✓ ROTO tilt-turn hardware for reliability
Shanghai G-Ren GFRPU Manufacturing & Applications
Material & Design Specifications
Frame & Profile
- Material: Glass Fiber-Reinforced Polyurethane (GFRPU) composite
- Profile Model: GR85 series with 85mm frame thickness
- Configuration: Turn-tilt dual action windows
- Glazing: Triplex tempered glass for safety and performance
Certifications & Standards
- Tested to: AS/NZS 4420.1-2016 (Australian/NZ standard)
- Compliant with: AS 2047-2014 (Windows and external glazed doors)
- Certified by: Intertek Testing Services (independent verification)
- Passive House: Energy-efficient design for net-zero buildings
Innovation: Airframe Technology
Shanghai G-Ren's advanced R&D capabilities are developing world-first airframe technology to replace traditional steel structural members. This innovation will deliver lightweight, high-strength composite structures that combine the durability of aerospace engineering with the efficiency of modular construction — enabling even faster deployment and superior performance for climate-resilient housing systems.
This next-generation technology is currently in development and will further enhance the Barkly system's structural capabilities and deployment speed.
Northwest Workforce Transition Village
Gudithulla Housing is establishing a 50-bed Indigenous workforce development hub in Mount Isa–Cloncurry, North West Queensland, supporting employment pathways for remote Indigenous workers into regional infrastructure and mining projects.
The village features 50 Barkly sleeping units, shared ablation facilities, training classrooms, and communal spaces on a 1.5–2 hectare site. Participants complete a 20-week residential readiness program covering workplace safety, life skills, and job preparation before transitioning into employment.
This project demonstrates how modular construction enables rapid deployment of community-scale facilities supporting Indigenous employment and economic participation.
Multi-unit Barkly cluster showing village scalability
50 Sleeping Units
Barkly 3×6 modular cabins providing comfortable, climate-controlled accommodation for program participants.
20-Week Program
Structured workforce readiness training including safety, life skills, and industry exposure for employment success.
Regional Impact
Supports CopperString 2032, mining operations, and infrastructure projects across North West Queensland.
New Concept
Kukatj Gkuthaarn Coastal Tourist Village
A 12-cabin beachfront tourist stopover on Kukatj Gkuthaarn Country — 100% solar powered, rainwater harvesting, composting toilets. Featuring 2-bedroom and studio Barkly units with floor plans and site layout.
View Full ConceptPowered by SipsBuild Structural Systems
SipsBuild, based in Perth, develops advanced Structural Insulated Panel (SIP) systems engineered for durability, thermal performance, and rapid construction. Their innovative technology platform underpins the performance and scalability of Barkly housing systems, tested and approved by Curtin University.
High strength-to-weight structures with advanced composites
Corrosion resistance in coastal and extreme climates
Reduced construction time with factory precision
Superior energy performance and thermal efficiency
Engineered for cyclone and extreme weather resilience
Precision SIP Production Line
Barkly Integrated Steel Frame
Designed for Deployment Anywhere
Barkly systems are adaptable across multiple housing needs and geographic contexts.
Disaster Recovery Housing
Remote and Regional Communities
Social and Affordable Housing
Workforce Accommodation
Climate Adaptation Projects
Emergency Accommodation
Our mission is to enable resilient housing solutions wherever they are needed most.
Founder-Led Mission
SipsPacific and Barkly were created to address the growing gap between housing need and construction capability.
Combining modular construction expertise, international manufacturing relationships, and a commitment to affordability and resilience, the company is focused on delivering scalable solutions to one of the defining challenges of our time.
